| TYPE |
OFF ROAD |
| ENGINE TYPE |
196.4CC, 4-STROKE, 1
CYLINDER |
| BORE AND STROKE (MM) |
69 x 53 |
| COMPRESSION RATIO |
9.2 TO 1 |
| COOLING |
AIR/OIL |
| IGNITION |
CDI |
| TRANSMISION |
5 SPEED WITH MANUAL CLUTCH |
| FINAL DRIVE |
CHAIN |
| STARTING SYSTEM |
ELECTRIC / KICK |
| CHASIS |
| FRONT SUSPENSION |
TELESCOPIC FORK |
| REAR SUSPENSION |
SINGLE SHOCK |
| FRONT BRAKE |
DISC 11.5 Ø IN |
| REAR BRAKE |
DISC 9.5 Ø IN |
| FRONT TIRE |
2.75 X 21 |
| REAR TIRE |
4.10 X 18 |
| OTHERS |
| DIMENSIONS (LxWxH) |
86” x 39” x 46" |
| SEAT HEIGHT |
36" |
| WHEELBASE |
56" |
| FUEL CAPACITY (US gts) |
2.64 GALLON |
| OIL CAPACITY(Us qts) |
N/A |
| DRY WEIGHT |
264 LBS |
| WARRANTY |
3 YEAR ENGINE, 18 MONTHS ALL
PARTS |
| COLORS |
BLUE, RED, ORANGE, BLACK |
|
|
|
2005 DIRT TRACKER 125/200 SPECS |
|
Type
|
Off Road
|
|
TYPE OF ENGINE
|
124cc, / 198cc, 4-STROKE, 1 CYLINDER
|
|
BORE AND STROKE (mm)
|
64.5 X 63.2 / 69 X 53
|
|
COMPRESSION RATIO
|
9.2 TO 1
|
|
COOLING
|
AIR
|
|
IGNITION
|
CDI
|
|
TRANSMISSION
|
5 SPEED WITH MANUAL CLUTCH
|
|
FINAL DRIVE
|
CHAIN
|
|
STARTING SYSTEM
|
ELECTRIC / KICK
|
|
CHASSIS |
|
SUSPENSION/FRONT
|
TELESCOPIC FORK
|
|
SUSPENSION/REAR
|
SWING ARM W/SINGLE SHOCK
|
|
BRAKES/FRONT
|
10.5 ØIN DISC
|
|
BRAKES/REAR
|
DRUM
|
|
TIRES/FRONT
|
2.75 X 21
|
|
TIRES/REAR
|
4.10 X 18
|
| OTHER |
|
L X W X H
|
86" X 39" X 46"
|
|
SEAT HEIGHT
|
34"
|
|
WHEELBASE
|
53.5"
|
|
FUEL CAPACITY (US GALLONS)
|
1.72
|
|
LUBRICATION OIL TANK CAPACITY (US qts)
|
NOT APPLICABLE
|
|
DRY WEIGHT (LBS)
|
247
|
|
WARRANTY (MONTHS)
|
36
|
|
COLORS:
BLUE, ORANGE |
